Blue-green infrastructure (BGI) reduce urban combined sewer overflows (CSOs) and stormwater outlets (SWOs). However, most conventional BGI are not designed to remove trace organic contaminants. Little is known about the potential of conventional BGI to improve surface water quality by reducing the discharge of trace organic contaminants. We derived wash-off loads for street runoff (6PPD-q, DPG, and HMMM), construction materials (diuron), and wastewater-derived contaminants (diclofenac) based on measurements in the combined sewer system. Subsequently, the performance of four BGI types (bioretention cells, green roofs, porous pavements, and urban wetlands) to reduce the discharge of trace organic contaminants via SWOs and CSOs was quantified with a hydrodynamic SWMM model. Moreover, the catchment-wide impact of SWOs and CSOs on surface water was assessed using risk quotients. We found that the annually discharged load can be considerably reduced by implementing BGI. Among the studied BGI types, bioretention cells are the most effective, with a load reduction of up to 80% to surface waters, mainly due to a larger suitable implementation area and a substantial stormwater infiltration. BGI implemented in the separate sewer system are more effective in reducing stormwater contaminant loads than BGI in the combined system. The assessment of the risk quotient in the surface water showed that the concentrations during SWO and CSO discharges exceed the acute environmental threshold in the surface water for 6PPD-q, DPG, diuron, and diclofenac during several events. The implementation of BGI reduced the hours of exceeded risk quotient in the surface water by 93% for bioretention cells. These findings underscore the need for a catchment-wide assessment of future BGI implementations to quantify, manage, and mitigate the impacts of urban pollution.

Indem blau-grüne Infrastrukturen die Mischwasserentlastungen reduzieren, werden auch die Einträge von Mikroverunreinigungen verkleinert. Besonders Versickerungsflächen senken die eingeleiteten Volumina und Frachten in Oberflächengewässer. Klimawandelprognosen lassen eine Zunahme von Entlastungen erwarten. Blau-grüne Infrastrukturen können daher einen wichtigen Beitrag leisten, um unerwünschte Effekte zu vermeiden oder zu reduzieren.

Combined sewer overflows (CSOs), the discharge of untreated sewage mixed with stormwater into surface waters, are expected to increase under climate change as a result of more extreme rainfall. Blue-green infrastructure (BGI), such as bioretention cells and porous pavements, can help to reduce the amount of stormwater entering combined sewer systems, thus reducing CSO discharge. However, our understanding of the potential for BGI to mitigate CSOs in a future climate is still lacking, as performance is typically evaluated for individual BGI elements with fixed implementation areas under historical climate conditions or limited future scenarios. In response, this study investigates the performance of 30 combinations of BGI elements and implementation rates to prevent increases in CSOs under a range of future climate scenarios in an urban catchment near Zurich, Switzerland. Median total annual rainfall, projected to increase by as much as 46%, could double the median annual CSO volume and increase median annual CSO frequency by up to 52%. Four BGI combinations that include bioretention cells show the most promise to prevent increases in CSO volume and frequency in a future climate; and given the diverse responses of BGI elements to distinct rainfall patterns, their combinations can enhance CSO discharge reduction across varying climate patterns. BGI is also likely to become more cost-effective under future climatic conditions as projected increases in total rainfall led to larger CSO volume reductions obtained through BGI. However, there is a trade-off between robustness to climate change and cost-effectiveness, since CSO volume reduction capacity scales with BGI implementation rate but cost-effectiveness declines. Our study illustrates the effectiveness of various BGI combinations to prevent increases in CSOs in a future climate, calling for a range of BGI elements and implementation areas to be considered for urban drainage adaptation.

By infiltrating and retaining stormwater, Blue-Green Infrastructure (BGI) can help to reduce Combined Sewer Overflows (CSOs), one of the main causes of urban water pollution. Several studies have evaluated the ability of individual BGI types to reduce CSOs; however, the effect of combining these elements, likely to occur in reality, has not yet been thoroughly evaluated. Moreover, the CSO volume reduction potential of relevant components of the urban drainage system, such as detention ponds, has not been quantified using hydrological models. This study presents a systematic way to assess the potential of BGI combinations to mitigate CSO discharge in a catchment near Zurich (Switzerland). Sixty BGI combinations, including four BGI elements (bioretention cells, permeable pavement, green roofs, and detention ponds) and four different implementation rates (25%, 50%, 75%, and 100% of the available sewer catchment area) are evaluated for four runoff routing schemes. Results reveal that BGI combinations can provide substantial CSO volume reductions; however, combinations including detention ponds can potentially increase CSO frequency, due to runoff prolongation. When runoff from upstream areas is routed to the BGI, the CSO discharge reductions from combinations of BGI elements differ from the cumulative CSO discharge reductions achieved by individual BGI types, indicating that the sum of effects from individual BGI types cannot accurately predict CSO discharge in combined BGI scenarios. Moreover, larger BGI implementation areas are not consistently more cost-effective than small implementation areas, since the additional CSO volume reduction does not outweigh the additional costs. The best-performing BGI combination depends on the desired objective, being CSO volume reduction, CSO frequency reduction or cost-effectiveness. This study emphasizes the importance of BGI combinations and detention ponds in CSO mitigation plans, highlighting their critical factors—BGI types, implementation area, and runoff routing— and offering a novel and systematic approach to develop tailored BGI strategies for urban catchments facing CSO challenges.

Green stormwater infrastructure (GSI) is growing in popularity to reduce combined sewer overflows (CSOs) and hydrologic simulation models are a tool to assess their reduction potential. Given the numerous and interacting water flows that contribute to CSOs, such as evapotranspiration (ET) and groundwater (GW), these models should ideally account for them. However, due to the complexity, simplified models are often used, and it is currently unknown how these assumptions affect estimates of CSOs, GSI effectiveness, and ultimately planning guidance. This study evaluates the effect on estimates of CSOs and GSI effectiveness when different flows and hydrologic processes are neglected. We modified an existing EPA SWMM model of a combined sewer system in Switzerland to include ET, GW, and upstream inflows. Historical rainfall data over 30 years are used to assess volume and duration of CSOs with and without three types of GSI (bioretention basins, permeable pavements and green roofs). Results demonstrate that neglect of certain flows in modelling can alter CSO volumes from -15 % to 40 %. GSI effectiveness also varies considerably, resulting in differences in simulated percent of CSO volume reduced from 8 % to 35 %, depending on the GSI type and modeled flow or process. Representation of GW within models is particularly crucial when infiltrating GSI are present, as CSOs could increase in certain subcatchments due to higher GW levels from increased infiltration. When basing GSI planning decisions on modeled estimates of CSOs, all relevant hydrologic processes should be included to the extent possible, and uncertainty and assumptions should always be considered.

Due to their cooling ability, sustainable roofing configurations, such as green and cool roofs, have the potential to increase solar panel yield, which is temperature dependent. However, the influence of sustainable roofing configurations on panel yield is not yet considered in rooftop photovoltaic (PV) planning models; thus, the significance of these integrated systems cannot be evaluated. In order to quantify the potential benefits of sustainable rooftops on solar energy, the first goal of this study is to develop a method that systematically accounts for roof surface characteristics in the simulation of PV panel energy yield. To do so, a rooftop energy balance model is linked with a physically-based solar energy model (the System Advisor Model, SAM) to quantify the energy yield of PV installations on sustainable roofing configurations. Roof surface temperatures are first estimated using non-linear energy balance equations, then integrated into a revised version of SAM to simulate energy yield. This new method improves the accuracy of PV yield simulations, compared to prior assumptions of roof surface temperature equal to ambient temperature. This updated model is used for the second goal of the study, to understand how four roofing configurations (black membrane, rock ballasted, white membrane, and vegetated) influence PV panel yield, which is currently not well understood in cooler climates. For a flat rooftop PV installation near Zurich, Switzerland (temperate climate), results show that, compared to a conventional roof, green roofs can increase annual PV energy yield, on average, by 1.8%, whereas cool roofs can increase it by 3.4%. For the case-study installation, an inverse correlation between the 95th-quantile roof surface temperature and the PV energy yield was identified; an increase of 1 °C leads to a 71 kWh reduction in energy yield per year. Overall, cool roofs outperform green roofs in terms of increases in PV energy yield; however, potential improvements of both systems are non-negligible, even in relatively cooler climate regions like Switzerland. By providing a systematic method to evaluate the influence of the roofing configuration on PV energy yield, solar energy planners are able to differentiate between the benefits of traditional and sustainable rooftop configurations - the first step towards the coupling of distributed energy and sustainable building systems. In the future, this integrated method could be used as part of a holistic evaluation of the environmental, economic, and social objectives of green and cool roofs, as well as, other infrastructure systems.
